Odyssey Battery ODS-AGM470FTT 12VDC 214Ah Specialty Battery

ODYSSEY Extreme Battery ODS-AGM470FTT (PC1800-FT)

Like an athlete that is both a sprinter and a long distance runner, the ODYSSEY Marine Dual Purpose battery has both massive starting power and amazing deep cycling capability – up to 400 cycles at 80% depth of discharge. With twice the overall power and three times the life of conventional marine batteries, the ODYSSEY battery is ideal for trolling, starting, and for powering the many on-board electronic accessories common in today’s boats and recreational vehicles.

Technical Specifications:

• Voltage: 12V
• Pulse (5 second) Hot Cranking Amps (PHCA): 1800A
• Cold Cranking Amps (CCA): 1300A
• HCA: 1600A
• MCA: 1450A
• 20Hr Nominal Capacity (Ah): 214Ah
• 10Hr Nominal Capacity (Ah): 190Ah
• Reserve Capacity Minutes: 475 mins
• Terminal: 3/8-16" Stud
• Torque Spec in-lbs (Nm max): 80 (9.0)
• Internal Resistance (mΩ): 3.3mΩ
• >Short Circuit (A): 3800A
• Recommended Min. Charging Current (A): 19A
• Operating Temperature Range: -40°F / -40°C to 113°F / +45°C
• Optimum Storage Temperature: 68°F / +20°C
• UPC: 635241140859
• Length: 22.90 in in
• Width: 4.92 in
• Height (terminals included): 12.50 in
• Height (container): 12.50 in
• Weight: 132.00 lbs
